Description of Swivel Lifting Plates
Swivel lifting plates, are specialized lifting devices used to secure and lift heavy loads. They consist of a lifting point or attachment point that can rotate or swivel, allowing for increased flexibility and safer lifting operations. It is a high-strength single-sided or edge-mounted insert for 3/4" or 1" bolt diameters. It is constructed of forged steel and is rated for a safe working load of 11,000 lbs with 1" bolts and 7,700 lbs with 3/4" bolts for an approximate 5:1 safety factor. Its internal Swivel pegs float and swivel horizontally to counteract telescoping, bending, or displacement deformation without stress spots. It is highly corrosion resistant and works very efficiently, reducing installation time considerably.These devices are commonly used in industries such as construction, manufacturing, and rigging, where heavy loads need to be lifted, moved, or suspended. They are designed to withstand substantial loads and provide a reliable and secure connection point.
It's important to note that while swivel lifting plates offer enhanced flexibility, they still have specified load capacities that should not be exceeded. It's crucial to follow the manufacturer's guidelines and ensure proper training and safety measures are in place when using these devices to prevent accidents or damage.P
| Name | Single Swivel Lift Plate | Double Swivel Lift Plate |
| Picture |  |
 |
Specification of Swivel Lifting Plates
1. Single Swivel Lift Plate
|
|
|||||||||||
| Part number |
Bolt diameter |
H overall height |
IH inside height |
L length |
W weight |
D |
T thickness |
PT plate thickness |
Minimun bolt length |
5:1SWL (lbs) |
Weight （lbs） |
| GME1234 | 3/4" | 8-1/8'' | 5-7/8'' | 5'' | 2-1/2'' | 4-1/4'' | 1-1/2'' | 9/16'' | 5'' | 11000 | 5.68 |
| GME1201 | 1'' | 8-1/8'' | 5-7/8'' | 5'' | 2-1/2'' | 4-1/4'' | 1-1/2'' | 9/16'' | 6'' | 11000 | 5.53 |
2. Double Swivel Lift Plate
|
|
||||||||
| Part number |
Bolt diameter |
H overall height |
IH inside height |
W weight |
T thickness |
Min.Bolt Length |
5:1SWL (lbs) |
Weight （lbs） |
| GME261 | 1" | 8-1/2'' | 5-1/2'' | 5'' | 1-29/32'' | 6-1/2'' | 10000 | 8.63 |
| GME26114 | 1-1/4'' | 9'' | 5-1/2'' | 7'' | 2-3/8'' | 7'' | 15000 | 16.94 |
| GME26112 | 1-1/2" | 9'' | 5-1/2'' | 7'' | 2-3/8'' | 7-1/2'' | 15000* | 16.79 |
Application of Swivel Lift Plate
Swivel lifting plates are typically designed for single-sided or edge-mounting applications. These inserts are made of forged steel, which provides high strength and durability. They are specifically engineered to withstand heavy loads and are rated for safe working loads, ensuring the safety of lifting operations.The swivel feature of these lifting inserts allows for greater flexibility when positioning and lifting loads. The ability to rotate or swivel the insert helps adjust the lifting angle and accommodate varying load configurations. This flexibility can be particularly useful in situations where precise positioning or alignment is required.
