Great Magtech (Xiamen) Electric Co., Ltd. is one of the leading manufacturers and suppliers of shuttering magnetic bar loaf magnets with groove in China. Please feel free to wholesale high quality shuttering magnetic bar loaf magnets with groove from our factory. If you have any enquiry about cooperation, please feel free to email us.
Description of Shuttering Magnetic Bar Loaf Magnets
The BR is a magnet that has been specially developed for applications in lateral and longitudinal stops and is mainly used in combination with U-profiles in the production of prefabricated ceilings and double walls.
The magnet must be a 100 percent fit for the profile. Therefore the BR is available in a large number of different dimensions, magnetic forces, and designs.
These permanent holding magnets can be used to hold steel panels, beams, fences, and molds in place. A provision on the magnet enables the user to rerelease the workpiece.
Shuttering magnets have a high holding force. To achieve this, good contact with the surface is necessary, since even a small air gap will reduce the holding force.
The series is a magnet that has been specially developed for applications in lateral and longitudinal stops and is mainly used in combination with U-profiles in the production of prefabricated ceilings and double walls.
Depending on requirements and the client's wishes, the magnet can be supplied with chamfers along the length or on the front, non-magnetic cover plates, or many other forms of processing. The magnetic strip is easy to release using a release lever.
Specification of Shuttering Magnetic Bar Loaf Magnets with Groove
| Number | L | b | h | N.W | Force |
| GME-BL-30/185 | 185 | 50 | 30 | 2.2 | 7500 |
| GME-BL-40/153 | 153 | 50 | 40 | 2.5 | 7500 |
| GME-BL-50/97 | 97 | 50 | 50 | 1.7 | 4500 |
| GME-BL-50/140 | 140 | 50 | 50 | 2.5 | 6500 |
| GME-BL-50/185 | 185 | 50 | 50 | 3.3 | 8000 |
| GME-BL-50/230 | 230 | 50 | 50 | 4.1 | 10000 |
| GME-BL Release | 2 | 22000 |
advantages of Shuttering Magnetic Bar Loaf Magnets
Suitable for use with circulation and robotic systemsMultifunctional for various applications
It is also extremely suitable to replace or add to existing shuttering
Easy to handle because of its low weight
No bulging of the magnet material because of the compact design
Application of Shuttering Magnetic Bar Loaf Magnets
The Shuttering Magnetic Bar Loaf Magnets installation and just need to locate the shuttering magnet into the exact position by hand. Normally if there is a slight wrong position, you can use a rubber hammer to fix it. The next step is installing the adaptor accessory and adjusting the tensile bar to fit your wooden mold height and support it tightly. The bottom magnetic system could afford powerful resistance force against the forms moving under the circumstance of pouring concrete and steel platform vibrating, due to the integrated neodymium magnets. After work is done, a special release bar is provided to release it and remove it for further maintenance or next use. The stainless case features outstanding performance for anti-rust, which greatly increases the magnet's use life.
Factory of Shuttering Magnetic Bar Loaf Magnets
The company has a group of experienced technical R&D personnel and professional production equipment including laser cutting machines, CNC electro-hydraulic bending machines, gantry milling machines, CNC lathes, imported flexible welding platforms, and other professional production equipment to ensure that product design is advanced, well-made and of excellent quality. Can provide professional customized services according to customer needs to meet the different needs of customers
Package of Shuttering Magnetic Bar Loaf Magnets
Air freight packaging
Foam box-iron sheet-double wall corrugated box-waterproof bag
Shipping packaging:
wooden box:
1. Use special fumigation-free wooden boxes for export and inner carton packaging
2. There is a plastic film on the outer layer to prevent the goods from getting damp.
Shipping packaging:
Wooden pallets:
1. Use export-specific fumigation-free pallets
2. Cartons need to have packing tape to facilitate transportation.
3. The entire pallet of goods needs to be stacked neatly and then reinforced with packing tape to prevent it from falling during transportation.
